Monocular Microscopes

• Monocular head 45° inclined 360° rotation • WF10x 18 mm lockable eyepiece • X4, x10, x40, x100 Semi-Planachromatic, DIN objectives • Built-in rackless mechanical stage • Coarse fine focus • 1.25 NA Abbe condenser with iris diaphragm • 3 W LED illumination • Immersion oil dust cover included • Dimensions: 245 x 190 x 380 mm • Weight: 6.8 kg • 5 year warranty

Specification: • Monocular head inclined 30° with built-in 5.0 mega pixel CMOS Camera • x10 wide field eyepiece • Achromatic objectives x4, x10, x40 • Quadruple revolving nosepiece • Coarse and fine focusing • Built-in mechanical stage • Focusable 1.25 N.A. Abbe condenser with iris diaphragm • Built-in halogen illumination 12V/20W with intensity control • Supplied with Motic Images Plus 2.0 Software (multi-language version) • USB 2.0 PC connection

The versatile BA50-X WiFi digital microscope represents the latest in educational technology. This digital microscope transmits live images to wireless laptops, iOS or Android Tablets. Featuring high-speed, full resolution imaging technology built into the head of the microscope, the BA50-X can be used as normal microscope with the built-in eyepiece, or used to share live images with your class, using WiFi tablets or Windows Laptops. Please note: connection to the microscope camera is exclusively over WiFi, using the microscope's own ad hoc network. The USB port is for power only. Specification: • Optical System: Finite optical system, 160 mm • Observation tube: Monocular with built in digital type Wi-Fi camera • Inclination: 30° inclined, 360° rotating • Camera sensor: CMOS 1/3"" 4.0 MP 1920x1080 pixels • Output: Wi-Fi transmission up to 1.3 MP • Eyepieces: WF10X/18 mm • Nosepiece: Reversed triple revolving nosepiece • Objective classification: Achromatic objectives, DIN • Objectives: 4X/0.10, 10X/0.25, X/0.65/S • Objective mounting thread: 4/5""x1/36"" (RMS standard) • Stage: Gliding stage with ""one-touch"" sample holder • Stage size: 105 mm (Diameter) • Upper limit stop: Upper limit stop pre-set but adjustable • Condenser: Built in 0.65 N.A. with disc diaphragm • Focus mechanism: Separate coarse and fine focusing system • Fine Focus precision: µm minimum increment • Z-axis movement: mm • Filter: Built-in frosted glass • Illumination: LED 20 mA, 3.5 V, 70 mW with intensity control • Transformer: External • Power supply: Charger 100-240 or rechargeable batteries • Accessories included: Calibration slide, dust cover, charger and batteries • Software: Motic Images Plus 3.0 for Windows, OSX and Linux, MotiConnect App for iOS and Android • Weight: 2.75 kg • Dimensions (L W H): 175 153 334 mm

A robust and easy to handle microscope with high-quality optics made of 100% coated glass for crisp and clear images. This LED model runs cool and features built-in rechargeable batteries and comes with mains charger. (Also available with fitted eyepiece graticule – see MI180312) Specification: • Monocular head inclined 45°, with 360° rotation • x10 wide field eyepiece with pointer • x4, x10, and x40 (R) DIN Objectives • Coarse and fine rack and pinion focusing • 0.65 NA condenser • LED 3.5V/70mW illumination with intensity control • Iris diaphragm with filter housing • Supplied with dust cover and blue filter • LIFETIME WARRANTY on optical components

A set of 10 robust and easy to handle microscope with high-quality optics made of 100% coated glass for crisp and clear images. This LED model runs cool and features built-in rechargeable batteries and comes with mains charger. (Also available with fitted eyepiece graticule – see MI180312/10) Specification: • Monocular head inclined 45°, with 360° rotation • x10 wide field eyepiece with pointer • x4, x10, and x40 (R) DIN Objectives • Coarse and fine rack and pinion focusing • 0.65 NA condenser • LED 3.5V/70mW illumination with intensity control • Iris diaphragm with filter housing • Supplied with dust cover and blue filter • LIFETIME WARRANTY on optical components

A robust and easy to handle microscope with high-quality optics made of 100% coated glass for crisp and clear images. Specification: • Monocular head inclined 45°, with 360° rotation • x10 wide field eyepiece with graticule • x4, x10, and x40 (R) DIN Objectives • Coarse and fine rack and pinion focusing • 0.65 NA condenser • Tungsten 220V/20W illumination • Iris diaphragm with filter housing • Supplied with dust cover and blue filter • LIFETIME WARRANTY on optical components

A robust and easy to handle microscope with high-quality optics made of 100% coated glass for crisp and clear images. Specification: • Monocular head inclined 45°, with 360° rotation • x10 wide field eyepiece with graticule • x4, x10, and x40 (R) DIN Objectives • Coarse and fine rack and pinion focusing • 0.65 NA condenser • Tungsten 220V/20W illumination • Iris diaphragm with filter housing • Supplied with dust cover and blue filter • LIFETIME WARRANTY on optical components

The BA50 is 3/4 size educational microscope with reversed nosepiece LED illumiation. Built-in batteries allow cordless operation. The rugged metal construction and precision mechanics should guarantee many years of use. Specification: • 3/4 size student microscope • Monocular head, inclined 45° and 360° rotating • Widefield eyepiece WF10X/18 mm with pointer • Reversed triple revolving nosepiece • Achromatic objectives 4X, 10X, 40X • Coarse and fine focusing system with tension adjustment • 0.65 N.A. condenser with disc diaphragm • LED illumination 20 mA, 3.5 V, 70 mW with intensity control • Includes dust cover, charger, batteries and calibration slide • Dust cover • 5 year warranty

A 3/4 sized basic microscope combining ease of operation with mechanical strength. Specification: • Vertical monocular head • x10 wide field eyepiece with pointer, lockable • x4, x10 and x40 objectives • Rack and pinion focusing • Rotary disc diaphragm • 42 mm plano-concave mirror • Coarse focussing system • Focussing stroke 28 mm • Dust cover included • 10 year warranty

A pack of 10, 3/4 sized basic microscope combining ease of operation with mechanical strength. Specification: • Vertical monocular head • x10 wide field eyepiece with pointer, lockable • x4, x10 and x40 objectives • Rack and pinion focusing • Rotary disc diaphragm • 42 mm plano-concave mirror • Coarse focussing system • Focussing stroke 28 mm • Dust cover included • 10 year warranty

A routine biological microscope for schools. Simple to handle, the separate coarse and fine focus mechanism facilitates teaching. The LED illumination with NA 0.65 condenser works well up to 40X objective magnification. Specification: • Monocular head inclined 45°, with 360° rotation • x10 wide field eyepiece with pointer, lockable • x4, x10 x40 DIN Achromatic objectives • Quadruple nosepiece • Built in 0.65 condenser • Coarse and fine focusing • Iris diaphragm with filter holder and blue filter • LED 3.5V/70mW substage illumination • Includes dust cover • 5 year warranty

A routine biological microscope for schools. Simple to handle, the separate coarse and fine focus mechanism facilitates teaching. The LED illumination with NA 1.25 condenser works well with a 100X objective magnification. Specifications: • Monocular head inclined 45°, with 360° rotation • x10 wide field eyepiece with pointer, lockable • x4, x10 x40 DIN Achromatic objectives • Quadruple nosepiece • Built in 1.25 focusable Abbe condenser • Coarse and fine focusing • Iris diaphragm with filter holder and blue filter • Upper limit stop preset but adjustable • LED substage illumination • Includes dust cover • 5 year warranty

A value monocular microscope with simple optical glass objectives mounted on a revolving nosepiece. It comes with a plastic stage with stage clips and a 6-hole disc condenser. The eyepiece tube is mounted at a 45 degree angle for comfortable viewing and has a wide-field eyepiece with built in pointer. In addition to the traditional bottom light, the microscope is provided with a top light and is thus also suited for observation of surfaces of objects such as leaves, coins, circuit boards, insects etc. The simplicity of the design makes it a good choice as an introduction to microscopes or as a supplement to the more traditional school microscope. Supplied with a dust cover. •Magnification: x40, x100, x400 •Objectives: x4, x10, x40 •Eyepiece: x10 widefield •Condenser: 6-hole disc •Illumination: Bottom light LED, Top light LED •Power: 3 x AA batteries and mains power •Focus: Coarse adjustment
