Drilling Machines

The machine can be supplied for left or right handed operation and for a small surcharge it can be supplied with the necessary parts for easy conversion in the workshop. TECHNICAL DATA • Drilling capacity in mild steel 13mm • Motor 0.25kW Single phase • Throat depth 194mm • Speed range 500-4000rpm • No. of speeds 5 • Table size 235 x 409mm • Dimensions 815 x 372 x 627mm • Weight 46Kg KEY FEATURES • Made in the UK • Bench mounted • Easy to use • Front mounted controls • Head raising mechanism

The machine can be supplied for left or right handed operation and for a small surcharge it can be supplied with the necessary parts for easy conversion in the workshop. TECHNICAL DATA • Drilling capacity in mild steel 13mm • Motor 0.25kW Single phase • Throat depth 194mm • Speed range 500-4000rpm • No. of speeds 5 • Table size 235 x 409mm • Dimensions 815 x 372 x 627mm KEY FEATURES • Made in the UK • Bench mounted • Easy to use • Front mounted controls • Head raising mechanism • Latching footswitch

Jacobs No.6 internal taper and K3 key.

For Craft & Supercraft chucks, 13mm & 16mm.

Key features: • Robust cast iron construction • Belt and pulley Drive - 4 speeds • Rack and pinion table raising mechanism • Integral easy to use depth stop • High quality induction motor • T slot table with centre hole • Slotted base • Tilting table • Integral high intensity LED work light • CE Approved Specification: Drilling Capacity: 3-16mm Spindle: 2MT Spindle Speed: 480,820, 1390, 2300rpm at 50Hz Spindle Travel: 110mm Column Diameter: 75mm Table Size (DxW): 225mm x 235mm Power reqirements: Single phase (230V) Power consumption: 0.375kW Dimensions: Height: 900mm Width: 345mm Depth: 670mm Weight: 94kg

The TS1B bench drill has a 13mm drilling capacity, 2 MT spindle and 4 speed operation. It is supplied with a Silverflame BT2 telescopic chuck guard. Key features: • Requires a single phase supply and 10A type C breaker at board • Integral footstop • Robust cast iron construction • Belt and pulley Drive - 4 speeds • Rack and pinion table raising mechanism • Integral easy to use depth stop • High quality induction motor • T slot table with centre hole • Slotted base • Tilting table • Integral high intensity LED work light • CE Approved

These drills have dedicated push button controls and all pedestal drills are fitted with a suitable foot operated emergency stop. The Woodpecker complies fully with the European Machinery Directive and also with BS 4163:2014 “Health and Safety for Design and Technology in schools and similar establishments"". Key features: • Aluminium drive pulleys • Wide range of spindle speeds • Motor power transmitted through two V-Belts • Depth stop and scale indicator • Fitted with keyless chuck for hand operation • Precision chuck arbor • Rack and pinion table raising mechanism • Cast Iron control handle with soft grips • Thick wall drill column • Working table with T-Grooves and full 360 degree rotation • Cast iron base with T-Grooves Safety features: • Microswitch on belt guard • No-volt overload push-button starter • Dedicated Push Button Controls • Emergency stop • Large adjustable telescopic chuck guards • All pedestal drills fitted with foot emergency stop • Ratchet table adjustment • Lockable table • Low noise level

For Craft & Supercraft chucks.

The hand-wheel is made from an ergonomically designed one piece casting for comfort of use whilst also providing additional weight to the headstock. These models come with 12 speeds making them ideal for drilling metal as well as wood. MT2 arbor No volt release switch Complete with 16mm chuck We strongly recommend footstop switches are added to these machines to comply with BS4163:2007.
