    Function Generator, Student Model

    Manufacturer: Timstar
    A high-quality simple-to-use student signal generator with a range of applications. Operated with just three buttons: Waveform, Frequency and Amplitude. There is a single output, provided with 4 mm safety sockets. The output can easily drive a speaker or vibrator with ample amplitude for resonance and diffraction experiments. The frequency range extends well beyond the audible range. The lowest frequencies are suitable for ""slow motion AC"" experiments. Unique frequency control The frequency is set with a speed-sensitive button. If you turn slowly, the last digit of the display is set. Turning faster, the response accelerates smoothly. The generator covers the six decades from 0.05 Hz to 50.00 kHz in a single range. The frequency is stable within 0.005 % Three waveforms The generator provides sine, triangle, or square wave signals. Distortion of the sine wave is less than 0.25 % in the audible range (20 Hz - 20 kHz) and remains below 1 % throughout the frequency range (0.05 Hz - 50 kHz). Built-in power amplifier The signal amplitude is continuously adjustable from 0 V to a peak voltage of 7.5 V (15 V p-p; 5.3 V RMS). More than 1 A peak current can be supplied. The output is overload protected. Supplied with 12 V power adapter.
    SKU: SS013166
    Manufacturer part number: SI180100
    Availability:
    Price: 2213.40 AED
    i h h
    Frederiksen Student Function Generator. A high quality, simple-to-use student signal generator with range of applications.Three controls: waveform, frequency, and amplitude, control the output. The waveform and frequency are displayed on the built-in LCD.Output is via pair of mm sockets. It can be used for most experiments involving sound or vibrations that would be carried out in school.• Overload protection• LCD screen• Power supply included
